High Speed Horizontal Servo / Electronic Tensioner With Cylinder 0.80 Mm

Product Details

Place of Origin: Hangzhou China

Brand Name: QIANHE

Model Number: QH-MTQM

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: US$ 105- US$300

Packaging Details: Carton with foam

Delivery Time: 3-7 work days

Payment Terms: T/T, Western Union

Supply Ability: 5000 set per month

Get Best Price
Highlight:

electronic tensioner

,

coil winder tensioner

,

Horizontal Electronic Tensioner

Name:
Magnetic Tensioner With Cylinder
Place Of Origin:
Hangzhou China
Materials:
Alloy Resin
Color:
White And Beige
Package Size:
240mmX200mmX110mm
Product Weight:
1.25kg
Name:
Magnetic Tensioner With Cylinder
Place Of Origin:
Hangzhou China
Materials:
Alloy Resin
Color:
White And Beige
Package Size:
240mmX200mmX110mm
Product Weight:
1.25kg
High Speed Horizontal Servo / Electronic Tensioner With Cylinder 0.80 Mm

High Speed Horizontal Servo / Electronic Tensioner With Cylinder 0.80 mm





Hangzhou Qianhe Precision Machinery Co.,Ltd



 we are professional manufacturer for coil winding tensioner with best quality and

most competitive price in China



 MTQ Series coil winding Magnetic Tensioner with Cylinder by using permanent magnet,

tension is generated to the damp wheel. The non contact mechanism design provides

 stable, consistence and precision tension to the wire. Excellence for both high and

normal speed winding. Coil winding magnetic tensioner with cylinder.



Key advantages of Magnetic wire tensioners:



MTQ series come with a tension release mechanism to assist in special operations such as

 wire hooking etc.All MTQ series enable back tension adjustment & also feature wire breakage

 detection switches.

Specification :



Products Series  Model Tension Scope Applied wire diameter Tension Rod
(g) (mm)
MTQ Series     (Horizontal type with Cylinder) QH-MTQSS 5-130 0.025-0.12 TR-1#
QH-MTQ300S 14-400 0.06-0.25 TR-5#
QH-MTQS 30-800 0.08-0.40 TR-6#
QH-MTQM 300-1500 0.35-0.80 TR-16#
QH-MTQL 500-2500 0.40-1.00 TR-21#





Detailed Product Description:



 MTQSS

  • Type : Horizontal Type
  • Applied wire diameter :Ф  0.35- Ф 0.80 mm
  • Tension Scope:  300-1500g
  • Tension Rod type : TR-16#

Hanging Line Diagram :



High Speed Horizontal Servo / Electronic Tensioner With Cylinder 0.80 Mm 0

Wire speed is 10m/s, instant start ,stop the continuous line ,stable tension is  ± 1%



Picture show:

High Speed Horizontal Servo / Electronic Tensioner With Cylinder 0.80 Mm 1

                                                                        MTQ  Series

High Speed Horizontal Servo / Electronic Tensioner With Cylinder 0.80 Mm 2

                                                                          MTA  Series

High Speed Horizontal Servo / Electronic Tensioner With Cylinder 0.80 Mm 3

                                                                             ETC Series

High Speed Horizontal Servo / Electronic Tensioner With Cylinder 0.80 Mm 4

                                                                                  MTC Series

High Speed Horizontal Servo / Electronic Tensioner With Cylinder 0.80 Mm 5

                                                              Coil winding machine tensioner
