Custom Coil Winding Nozzle With precision grinding , HRC 60-90 degree Hardness

Product Details

Place of Origin: Hangzhou China

Brand Name: QIANHE

Model Number: Be made according to dimensions drawing

Payment & Shipping Terms

Minimum Order Quantity: 10pcs

Packaging Details: carton with bag

Delivery Time: 7-15 days

Payment Terms: T/T, Western Union

Supply Ability: 5000 pcs per month

Get Best Price
Highlight:

wire guide tubes

,

Tungsten Carbide Nozzle

Materials:
Hard Alloy/ Carbide Steel
Hardness:
HRC 60-90 Degree
Applied:
Stator And Rotor
Roughnes Of R Place:
Ra 0.025
Roughness Of Bore:
Ra 0.1
Polish:
Precision Grinding
Materials:
Hard Alloy/ Carbide Steel
Hardness:
HRC 60-90 Degree
Applied:
Stator And Rotor
Roughnes Of R Place:
Ra 0.025
Roughness Of Bore:
Ra 0.1
Polish:
Precision Grinding
Custom Coil Winding Nozzle With precision grinding , HRC 60-90 degree Hardness



Motor Nozzle :



We are professional Manufacturer for Motor coil winding nozzles,wire guide tubes,

wire guide needles,wire guide eyelets with competitive price in china.



The product adopts hard alloy or carbon steel heat treatment and receives precision grinding

and polishing by professional processing equipment .Therefore, it boasts high resistance to

flexure and to wear and is extensively applied in fields of series, fan, micro-motor and motor

for wire coiling of stator and rotor.



Specification :



Be made according to dimensions drawing.



Measurements:

Customize available by requested in dimensions drawing, outside diameter is governed by

nozzle wall thickness. The measurements drawing denpend on confirm your nozzles

measurements according to your winding machine and coil products or your nozzle samples.





Picture show :







Custom Coil Winding Nozzle With precision grinding , HRC 60-90 degree Hardness 0
