Precision grinding Wire Guide Tube with Carbide Steel / Hard Alloy materials

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  Precision grinding Wire Guide Tube with Carbide Steel / Hard Alloy materials

Product Details:
Place of Origin: HANGZHOU CHINA
Brand Name: QIANHE
Model Number: Be made according to dimensions drawing
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Packaging Details: carton with bag
Delivery Time: 7-15 days
Payment Terms: T/T, Western Union
Supply Ability: 5000 pcs per month
Detailed Product Description
Model No: 10-Φ4.0-20 Hardness: 90 Degree
Material: Carbide Steel /Hard Alloy Polish: Precision Grinding
Advantage:: With High Rigidity And Hardness Transport Package: Special Packing
Ruby Nozzle Price: Factory Direct HS Code: 8479909090
High Light:

wire guide tubes

,

Tungsten Carbide Nozzle



High Hardness Alloy Wire Nozzle,

Coil Winding Wire Guide Nozzle
Tungsten Carbide Nozzle/High Hardness Alloy Wire Nozzle
Wire Guider Nozzle with Mirror Surface Treatment Hard Alloy Nozzle
Product Category: Nozzle series


Product Features:

This product is made of super hard alloy material precision machining, its hardness up

to HRA90 above, this product at both ends and the inner hole all for mirror processing,

in order to protect the enamel covered wire is not scratched. With high rigidity and hardness,

not easy to bend and plug, impact resistance.



Can be produced in accordance with customer requirements!

Eliminate wire insulation film damage, low friction resistance, stable wire tension.

The wire-guiding surfaces are mirror finished by diamond lapping to a surface

roughness of 2 -4 micro inches Ra or better, material permit.



Superior and inferior quality of alloy wire nozzle:

1 Nozzle orifice finish:
At the junction of its location, hole and arc angle, by visual method is unable to see, only with

the high magnification magnifier to observe the side, if there is an obvious mark junction hole

and transition arc angle, then the result is brought about by it scratch the enameled wire, if the

quality of the nozzle, at the junction of the inner hole and the arc angle it is a natural excessive,

no transfer of marks.

2 In the hole:
It is the quality of the product is also very crucial in the process of product winding in the inner

hole of the enameled wire is in the mouth of the online beating state, if the internal hole

grinding processing is not good, so the scraped line and then the inevitable worth to remind is,

now on the market a lot in hole alloy wire mouth is without grinding precision or simple rough

machining.
3 Hole size precision:
Precision machining line mouth, its inner hole accuracy can be controlled within 0.01mm, if the hole

size is greatly small, break phenomenon often occurs, even the winding insulation failure or interturn

short circuit is not hard to explain why.

4 Installation size precision

According to the consistency of the packing size is necessary, if it is hard to put into a small equipment fixture, it is easy to fall out of fixture and influence adjustment precision.

5 head and tail shape:
R line shape is a key part of the R mouth of the head and tail, R is too large or too small will influence

the quality of products and can withstand the tension.



Nozzle Drawings for example :

Precision grinding Wire Guide Tube with Carbide Steel / Hard Alloy materials 0

Picture show :

Precision grinding Wire Guide Tube with Carbide Steel / Hard Alloy materials 1



Precision grinding Wire Guide Tube with Carbide Steel / Hard Alloy materials 2
