Dc48V High Power Brushless Motor Tensioner

video play

Large Image :  Dc48V High Power Brushless Motor Tensioner

Product Details:
Place of Origin: Hangzhou China
Brand Name: QIANHE
Model Number: SF800-II
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: US$500-US$1000per set
Packaging Details: Carton with foam
Delivery Time: 3-15 working days
Payment Terms: T/T, Western Union ,Paypal
Supply Ability: 500 set per month
Detailed Product Description
Power Supply: DC36-48V Volgage: 100W
Mounting Hole: Ф 16mm Wire Speed: 20m/s
Feature: Feed Wire Automaticly Tension Range: 2-800g
Wire Range: 0.02-0.4mm Color: White
Delivery: By Air Application: Coil Winder
High Light:

brushless motor tensioner


dc48v motor tensioner


100W motor tensioner



Servo Tensioner

Servo tensiner Unlike traditional tensioning methods,Servo tension device feed the wire automatically depends on the winding requirement.

The tension generate by servo controlled tensiner is very much more stable and consistence,by replacing the spring and tension arm to change its value, this product comes with tension feedback stabilization system that can automatically tension stable equilibrium.compare with mechanical or magnetic type.

Tension can be set from 2g to 800g,it depends on the model.

Servo motor and control system are all packed within the body,SF series is solid and compact in design.

It operates with DC36V electric power.



I.Products Features:

The servo tensioner uses a DC Servo Motor and a Drive as a active wire feeding mechanism.

Its main features are as following :

1,Follow the speed of the winding machine,Active wire feeding

2,DC Servo Motor with High Precision Encoder and Advanced Driving Technology:

A,High following accuracy, good tension stability, acceleration and deceleration up to 0.2S;

B,High speed, high torque, large tension range, simple selection;

C,High efficiency, energy saving and low power consumption. The motor and drive work for a long time

with very low heat generation and no need for heat dissipation.;

D,Stable on-line measurement;

E,It can directly adjust the parameters of motor and the working angle of tension arm by connecting the

USB interface of tensioner with PC software. It is suitable for winding various coil products of various winding machines.

3. Wire speed up to 20 m/s.



Supply Ability

Supply Ability: 1000 Set/Sets per Month


Packaging & Delivery

Packaging Details:Coil Winding Tensioner Servo Wire Tensioner for Fine Copper Wire with package by       foam and carton box .


Port:                      Hangzhou /Shanghai /Ningbo


Lead Time :          1-5 working days




Specification :



Servo Tensioner
Part.No Tensioner model Tension Arm Tension Sprin  Tension Range (gf) Wire Range(mm) Tension bar head structure Tension rod size
1 SF800-II SF-1# T1,T2,T3 2-50 0.02-0.1 Ceramic Eylet/Ruby ,Wire Roller(S) Φ0.8*Φ2*150
2 SF800-II SF-2# T2,T4,T5 5-100


Ruby / Wire Roller(M) Φ1.5*Φ2*200
3 SF800-II SF-3# T5,T8,T9 30-450 0.06-0.28 Ruby / Ceramic Pulley(005)/Wire Roller(M) Φ1.5*Φ4*200
4 SF800-II SF-4# T7,T9,T10 100-800 0.12-0.40 Ruby / Ceramic Pulley(005)/Wire Roller(L) Φ2.0*Φ4.0*150


Main parameters


Product Model Power Power Input Air Pressure Mounting Hole Weight Product Size
SF800-II DC36V 100W / Ф 16mm 2.3kg 288*170*62(mm)


Dimensional drawing

Dc48V High Power Brushless Motor Tensioner 0

Product Structure

Dc48V High Power Brushless Motor Tensioner 1





Picture Display:


Dc48V High Power Brushless Motor Tensioner 2


Dc48V High Power Brushless Motor Tensioner 3


Dc48V High Power Brushless Motor Tensioner 4


Dc48V High Power Brushless Motor Tensioner 5

                                              Servo Tension Packing
