Low Frequency Tranformers Coil Winder Magnetic Tensioner For Fine Wire

Product Details

Place of Origin: HANGZHOU CHINA

Model Number: QH-MTAS

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: US$100-US$500

Packaging Details: Carton with Foam

Delivery Time: 3-5 working days

Payment Terms: T/T, Western Union

Supply Ability: 5000 set per month

Get Best Price
Highlight:

coil winding parts

,

Coil Winding Tensioner

,

Low Frequency Transformer Magnetic Tensioner

Brand Name:
Qianhe
Place Of Origin:
Hangzhou China
Color:
White And Beige
Package Size:
210mmX150mmX160mm
PProduct Weight:
0.50 Kg
Type:
Vertical Type
Mertials:
Alloy Resin
Function:
Tension Control
Brand Name:
Qianhe
Place Of Origin:
Hangzhou China
Color:
White And Beige
Package Size:
210mmX150mmX160mm
PProduct Weight:
0.50 Kg
Type:
Vertical Type
Mertials:
Alloy Resin
Function:
Tension Control
Low Frequency Tranformers Coil Winder Magnetic Tensioner For Fine Wire



Low-Frequency Tranformers  coil Winder Tensioner Magmetic Wire Tensioner for fine wire Ф0.08-Ф0.40mm



Hangzhou Qianhe Precision Machinery Co.,Ltd



 Qianhe  is a professional manufacturer for coil winding tensioner,  We offer  Magnetic tensioner,electronic tensioner and servo tensioner

 for coil winding machine with best quality and the most  competitive price in china.

there is description about Magnetic tensioner as following:



Key advantages of Magnetic wire tensioners:



These magnetic tensioners use a device containing a permanent magnet as a

 non-contact method of generating a variable resistance to rotation of the main

wheel of the tensioner, thus maintaining wire tension at the set value for longer

periods than their mechanical counterparts with greatly reduced requirement for

adjustment.

  • Polished ceramic eyelets and guide rollers at each point of contact protect   the  insulating enamel from mechanical damage.
  • The performance of these magnetic wire tensioners is exceptional given the low    cost,
  •  providing outstanding value for money.
  • Captive roller on tension arm is easy to thread, eliminates chance of losing wire.

Specification :



Products Series  Model Tension Scope Applied wire diameter Tension Rod
(g) (mm)
MTA Series      (horizontal type) QH-MTASS 5-130 0.025-0.12 TR-1#
QH-MTA300S 14-400 0.06-0.25 TR-5#
QH-MTAS 30-800 0.08-0.40 TR-6#
QH-MTAM 300-1500 0.35-0.80 TR-16#
QH-MTAL 500-2500 0.40-1.00 TR-21#


Hanging line diagram

Low Frequency Tranformers Coil Winder Magnetic Tensioner For Fine Wire 0

Tensioner test conditions :

Line speed is 15M/S, instant start, stop the continuous line, stable tension in the positive

and negative 1%g.



Key features of Type MTC300S :

  • Tension Scope :30-8000g
  • Applied wire diameter : 0.08-0.40
  • Tension Rod :  TR-6#

Picture show:

Low Frequency Tranformers Coil Winder Magnetic Tensioner For Fine Wire 1

                                                                                 MTAS

Low Frequency Tranformers Coil Winder Magnetic Tensioner For Fine Wire 2

                                                             Coil Winding Machine Tensioner
