Professional Nittoku White Ceramic Coil Winding Nozzle 0.3 mm Inner Bore

Product Details

Place of Origin: Hangzhou China

Brand Name: QINAHE

Model Number: TC1003-3008-3006

Payment & Shipping Terms

Minimum Order Quantity: 20 pcs

Price: US$12.5-US$25

Packaging Details: Carton with box/foam

Delivery Time: 3-10 working days

Payment Terms: T/T, Western Union

Supply Ability: 5000 pcs per month

Get Best Price
Highlight:

wire guide tubes

,

Tungsten Carbide Nozzle

Place Of Origin:
Hangzhou China
Materials:
Ceramic
Color:
White
Hardness:
1500HV
Flexural Strength:
1700N/mm²
Place Of Origin:
Hangzhou China
Materials:
Ceramic
Color:
White
Hardness:
1500HV
Flexural Strength:
1700N/mm²
Professional Nittoku White Ceramic Coil Winding Nozzle 0.3 mm Inner Bore

Professional Nittoku White Ceramic Coil Winding Nozzle 0.3 mm Inner Bore





Coil winding nozzle ,tungsten carbide nozzle ,Ruby Nozzle ,Ceramic Nozzle China
manufacturer.

This Nozzle made from NMparticles of zirconia material ,with hardness 1500HV, flexural strength
1700N/mm² ,using professional equipment for precision grinding ,The curvature radius of scientific
computing for both the inlet and outlet ,ensure the safety smoothly for the wire ,effective ensure the enameled wire paint from damage .

Specification  and size list :



Part.No. Model Specifications(mm)
ФD ФD1 Фd1 Фd2 L1 L
1 TC1003-3008-3006 0.8  0.3  1.0  30
2 TC1003-3010-3510 1.0  0.3  1.0  10  35
3 TC1005-3010-3008 1.0  0.5  1.0  30
4 TC1005-3010-3510 1.0  0.5  1.0  10  35
5 TC1207-3014-3008 1.4  0.7  1.2  30
6 TC1210-3020-3010 2.0  1.0  1.2  10  30



Size Drawings:
Professional Nittoku White Ceramic Coil Winding Nozzle 0.3 mm Inner Bore 0

Example :TC0303-3010-3008

TC (Ceramic Tungsten Alloy )
d2 =0.3 mm : Inner bore
d1 =0.3 mm : Outlet bore
D  =3.0 mm : Diameter
D1 =1.0 mm : Diameter
L  =30  mm : The total length
L1 =8.0 mm : Length

Pictures Show :

Professional Nittoku White Ceramic Coil Winding Nozzle 0.3 mm Inner Bore 1
                                                                    Ceramic Nozzle
