Product Details
Place of Origin: Hangzhou China
Brand Name: QINAHE
Model Number: TC1207-3014-3510
Payment & Shipping Terms
Minimum Order Quantity: 20 pcs
Price: US$12.5-US$25
Packaging Details: Carton with box/foam
Delivery Time: 3-10 working days
Payment Terms: T/T, Western Union
Supply Ability: 5000 pcs per month
Place Of Origin: |
Hangzhou China |
Materials: |
Ceramic |
Color: |
White |
Hardness: |
1500HV |
Flexural Strength: |
1700N/mm² |
Place Of Origin: |
Hangzhou China |
Materials: |
Ceramic |
Color: |
White |
Hardness: |
1500HV |
Flexural Strength: |
1700N/mm² |
Coil Winding Tungsten Carbide Nozzle for NITTOKU Machine 35mm length
Coil winding nozzle ,tungsten carbide nozzle ,Ruby Nozzle ,Ceramic Nozzle China
manufacturer.
This Nozzle made from NMparticles of zirconia material ,with hardness 1500HV, flexural
strength 1700N/mm² ,using professional equipment for precision grinding ,The curvature
radius of scientific computing for both the inlet and outlet ,ensure the safety smoothly for
the wire ,effective ensure the enameled wire paint from damage .
Specification and size list :
| Part.No. | Model | Specifications(mm) | |||||
| ФD | ФD1 | Фd1 | Фd2 | L1 | L | ||
| 1 | TC1003-3008-3006 | 3 | 0.8 | 0.3 | 1.0 | 6 | 30 |
| 2 | TC1003-3010-3510 | 3 | 1.0 | 0.3 | 1.0 | 10 | 35 |
| 3 | TC1005-3010-3008 | 3 | 1.0 | 0.5 | 1.0 | 8 | 30 |
| 4 | TC1005-3010-3510 | 3 | 1.0 | 0.5 | 1.0 | 10 | 35 |
| 5 | TC1207-3014-3008 | 3 | 1.4 | 0.7 | 1.2 | 8 | 30 |
| 6 | TC1210-3020-3010 | 3 | 2.0 | 1.0 | 1.2 | 10 | 30 |
Size Drawings:
Example :TC0303-3010-3008
TC (Ceramic Tungsten Alloy )
d2 =0.3 mm : Inner bore
d1 =0.3 mm : Outlet bore
D =3.0 mm : Diameter
D1 =1.0 mm : Diameter
L =30 mm : The total length
L1 =8.0 mm : Length
Pictures Show :
Nozzle inner bore
